Englander Blue Ridge 500 Wood Stove 2,700 sq. ft. New

The Englander Blue Ridge 500 Wood Stove ESW0012 features a high-efficiency 3.5 ft³ firebox, ensuring long-lasting comfort, capable of up to 10 hours of burn time. Crafted for durability, it boasts a 5/16″ steel top reinforced with a heat shield, a cast iron door, and ceramic glass, combining both strength and elegance. With EPA certification and a non-catalytic combustion system, it burns cleaner and more efficiently. Proudly made in the USA, this stove is not only environmentally responsible but also perfect for mobile home and alcove installations.

HIGHLIGHTS:
• Perfect for areas up to 2,700 sq. ft.
• Limited 5 year warranty on parts
• Brand new in box
• Ships directly from IN

FEATURES:
• Heats up to 2,700 ft²
• High efficiency 3.5 ft³ firebox
• Up to 10 hours burn time
• 5/16″ steel top reinforced with a heat shield
• Cast iron door and ceramic glass
• EPA certified
• Proudly made in USA
• Non-catalytic combustion system
• Certified for mobile home and alcove installation
• Qualifies for the 30% US tax credit

SPECIFICATIONS:
Door type: Single, glass with cast iron frame
Door opening size (Width): 19″
Door opening size (Height): 9 7/8″
Glass type: Ceramic glass
Glass surface – W x H: 16 5/8″ x 11 3/4″
Steel thickness-body: 3/16″
Steel thickness-top: 5/16″
Firebox size (Width): 22 7/8″
Firebox size (Height): 13″
Firebox size (Depth): 20 1/8″
Log positioning: Loading over width and over depth
Maximum log length: 22″ oriented East-West
Firebox lined with refractory bricks: Yes
Baffle type: High quality vermiculite
High-efficiency certified appliance: Yes, EPA 2020 approved
Canadian Standard (emissions): CSA B415.1-10
USA Standard (emissions): EPA
Canadian Standard (safety): ULC S627
USA Standard (safety): UL 1482, UL 737
Warranty: Limited 5 years
Clearance – Back wall: Single wall pipe- 13 3/4″ Double wall pipe- 8″
Clearance – Side wall: Single wall pipe- 22″ Double wall pipe- 19″
Clearance – Corner: Single wall pipe- 12″ Double wall pipe- 12″
Clearance – Base of the unit to ceiling: Single wall pipe- 84″ Double wall pipe- 84″
Fuel type: Dry cordwood (16″ recommended)
Recommended heating area: 1,000 – 2,700 ft²
Overall firebox volume: 3.5 ft³
EPA loading volume: 2.88 ft³
Maximum burn time: 10 h
Maximum heat output-dry cordwood: 110,000 BTU/h
Minimum overall heat output rate: 17,200 BTU/h (5.0 kW)
Maximum overall heat output rate: 57,800 BTU/h (16.9 kW)
Average overall efficiency-dry cordwood (HHV): 71 %
Average overall efficiency-dry cordwood (LHV): 76 %
Optimum efficiency: 77 %
Optimum heat transfer efficiency: 75 %
Average particulate emission rate: 1.6 g/h
Average CO: 73 g/h
From serial #: 100
Certifications: EPA-2020
Short description: High efficiency 3.5 ft³ firebox
Alcove installation approved: Yes
Mobile home approved: Yes, with fresh air intake
Certified according to applicable standards: CAN/USA accredited laboratory
Overall dimension (Width): 28 1/8″
Overall dimension (Height): 35 1/8″
Overall dimension (Depth): 31 1/4″
Premium quality blower included (CFM): Optional
Combustion technology: Non-catalytic
Stainless-steel secondary-air system: Yes
Flue outlet diameter: 6″
Distance-center of the flue outlet to back unit: 8″
Distance-center of the flue outlet to side unit: 14 1/8″
Recommended chimney diameter: 6″
Type of chimney: ULC-S629, UL 103 HT (2100 °F)
Minimum chimney height: 12′
PACKAGE CONTENTS: Wood Stove, Pedestal, Ash drawer & lip, Air intake damper, Rear air deflector, Manual
